Gas Tilting Bratt Pan 60L – 13kW | Industrial Cooking Equipment
The TechShop Engineering Gas Tilting Bratt Pan (60L) delivers exceptional performance for industrial and commercial kitchens. Built from premium-grade stainless steel, this heavy-duty unit features automatic tilting, multi-step temperature control (50–300°C), and homogeneous heat distribution, making it ideal for frying, boiling, braising, or sautéing in high-volume food production environments.
Need Instant Quotation or Custom Machine Specs?
Connect directly with our manufacturing engineers for price estimates, custom CAD design, and delivery schedule.
Technical Overview
The Gas Tilting Bratt Pan – 60L (13kW) from TechShop Engineering is an advanced industrial-grade cooking system engineered for reliability, precision, and efficiency. It’s an all-in-one solution for restaurants, catering services, and food processing industries, ensuring consistent cooking performance and safety.
-Build Quality & Materials
-
Constructed from 18/8 Cr-Ni stainless steel with a 2mm-thick satin-finished body for maximum durability and hygiene.
-
Features a double-walled stainless steel lid designed for reinforcement and long-term heat retention.
-
Equipped with an additional welded metal base for superior heat distribution and stability.
-
Fitted with adjustable stainless-steel pipe legs for perfect alignment on any surface.
-Performance Highlights
-
High-performance 13kW gas burner with pipe-type design ensures even heating across the cooking surface.
-
Automatic tilting mechanism (85°) for effortless emptying and cleaning.
-
Multi-step thermostat (50°C–300°C) for precise temperature adjustment.
-
Flame failure safety system automatically shuts off gas if the flame goes out.
-
Compatible with LPG or Natural Gas (G31, G25, G25.1, G27, G2.350) — easily convertible without modifications.
-
Automatic ignition button for fast and safe startup.
-
Limit thermostat protection automatically stops power supply in case of overheating.
-Applications & Industries
This bratt pan is perfectly suited for:
-
Hotels and restaurants
-
Industrial kitchens and canteens
-
Catering and food production plants
-
Institutional kitchens (schools, hospitals, factories)
It can perform multiple cooking tasks — frying, boiling, braising, searing, and simmering — making it an essential tool for large-scale operations.
-Key Benefits for Customers
Energy-efficient performance with excellent heat retention
✅ User-friendly tilting system for easy operation and cleaning
✅ Robust stainless-steel construction for long-term durability
✅ Accurate temperature control for consistent cooking results
✅ Safe operation with advanced gas control and flame protection
| Parameter | Specification |
|---|---|
| Model | TBP-60 |
| Device Capacity | 60 Litres |
| Total Power | 13 kW |
| Gas Inlet | ¾ inch |
| Gas Consumption | 11180 Kcal/h |
| Temperature Range | 50°C – 300°C |
| Cooking Area (W×D×H) | 710×435×200 mm |
| Tilting Angle | 85° (Automatic) |
| Material | 18/8 Cr-Ni Stainless Steel (2mm thick) |
| Lid Type | Double-walled stainless steel |
| Heating Type | Gas |
| Gas Type | LPG / Natural Gas (Convertible) |
| Ignition System | Automatic Ignition |
| Safety Features | Flame Failure Protection, Limit Thermostat |
| Feet Type | Adjustable Stainless-Steel Pipe Legs |
| Control Type | Multi-Step Thermostat Control |
